150 Kw and 225 Kw Power Options and 1700 Kg Weight for Efficient Top Feed Vibroflot Vibro Compaction

150 Kw Power Top Feed Vibroflot

225 Kw Power Vibroflotation Equipment

1700 Kg Weight Vibro Compaction Machine

起源の場所:

中国

ブランド名:

BVEM

証明:

CE、ISO 9001:2000、ISO 9001:2008

モデル番号:

BJVH-350-150、BJVEF-450-225

書類:

BVEM-Top Feed Vibroflot.pdf

私達に連絡しなさい

引用を要求しなさい

プロダクト細部

力:

150Kw、225Kw

重さ:

1700kg、2250kg

寸法(長さ*幅*高さ):

2250*650*340mm、3150*750*450mm

パワータイプ:

油圧式、周波数可変式

アプリケーション:

バイブロコンパクション、バイブロリプレイスメント

最大。スピード:

2600-2900rpm、1450-1740rpm

最高。広さ:

11mm、20mm

遠心力:

250-350Kn、520Kn

保証:

1 年または 2000 時間 (いずれか早い方)

支払及び船積みの言葉

最小注文数量

1セット

パッケージの詳細

木製ケース

受渡し時間

35〜60日

支払条件

T/T、L/C

供給の能力

600セット/年

関連製品

私達に連絡しなさい

86--13581545619

tianss@bjvibro.com

86-010-69592173

今接触

製品の説明

Top Feed Vibroflot with 150 Kw and 225 Kw Power Options

High-performance vibro compaction equipment available in 1700 kg weight configuration for efficient foundation treatment.

Comparative Analysis of Vibroflotation Equipment Series

Technical specifications and optimal application scenarios for different vibroflot models:

1. Conventional Electric Models

Technical Features:

Simple structure with constant speed operation
Low maintenance requirements
Ideal for projects requiring stable vibroflotation parameters

Model	Specifications	Applications
BJVE-426-180	426mm diameter, 180kW power	Medium-scale foundation treatment projects Dual-purpose for compaction and replacement stone columns Optimal pile spacing: 3-4m
BJVE-450-260	450mm diameter, 260kW power, 26mm amplitude, 440kN centrifugal force	Large-scale hydraulic fill sand compaction Recommended pile spacing: 4-5m Reduces number of piles and construction costs

2. Hydraulic Model (BJVH-350-150)

Technical Features:

Hydraulic system driven with high speed (2600-2900rpm)
Fast vibration frequency and quick response
Lower centrifugal force and amplitude compared to electric models

Application Scenarios:

Rapid penetration in complex hard geological conditions
Smaller pile diameters for replacement stone columns
Enhanced pile diameter control and material cost reduction

3. Electric Variable-Frequency Model (BJVEF-450-225)

Technical Features:

Variable-frequency technology with adjustable speed (1450-1740rpm)
Flexible vibration parameter adjustment
High centrifugal force (520kN) and large amplitude (20mm)

Application Scenarios:

Adjustable penetration capacity in complex geological formations
Extended vibration influence range for compaction projects
High-performance solution with superior adaptability
